AWK 160-240
Description
The automatic crossfeed grinders with their strong drives meet the highest demands on processing and hourly output. They are very suitable for the processing of big meat parts, fresh and frozen up to −16°C. The MultiGrind grinders can be equipped with the Enterprise cutting system in sizes E52 or E56 or the Unger cutting system in sizes 130 or 160.
- Cutting system Unger E130 Perforated plate-Ø 130 mm
- Total hopper volume ~360 Ltr.
- Hourly output with 3mm perforated plate ~3000 kg/h
- External dimensions (W x D x H) 1478 x 1496 x 1975 mm
- Motor voltage (3Ph) 400 V
- Motor main drive / Protection system IP55 15 (22) kW
- Motor feeding drive / Protection system IP55 1,5 kW
- Motor loosening device drive / protection system IP55 1,5 kW
- Nominal current at 400 V – Main drive 28,5 (40,5) A
- Nominal current at 400 V – Feeding drive 3,1 A
- Nominal current at 400 V
- Mixing and loosening device drive (opt.) 3,1 A
- Conductor size 10 (16) mm²
- Fusing at 400 V (A lazy) 40 (50) A
- Input height 1978 mm
- Lower housing height (with cover) 720 mm
- Noise level 68,8 db (A)
- Weight (net.) ~950 – 1050 kg
