Electro-mechanical lifting and tilting device for canisters and tanks
Stainless steel construction, AISI 304 (1.4301) with the exception of the the turning pivot shaft. Designed for lifting and tilting of canisters with capacity 200l. Lifting and tilting height: 1050 ч 4050 mm; For height over 3050 mm a special fortification of the equipment column is necessary. Depending on customer’s needs, the equipment can be connected stationary to the floor of the premises or mounted to a special wheel carrier. The mobile model can have maximum tilt-over height 2050mm. High reliability and safety work thanks to a load lifting system with a double roller chain.
Technical data:
Max. loading capacity: 300 kg
El. connection: 400 V/50 Hz
Power installed: 0,79 kW
Lifting speed: 5 m/min
| Art.№* | AxBxC (mm) | Type | Tilt-over height (mm) |
|---|---|---|---|
| 03.12.315.000 | 975x1100x3160 | left | 1850 |
| 03.12.325.000 | 975x1100x3160 | right | 1850 |
| Type | left, right |
|---|
